Axon Panel Textured

MODERN PANEL COLLECTION TO BRING TEXTURE AND INTEREST TO YOUR DESIGN.

Creating a strong visual impact for your building is easier than ever with Axon™ Panel Textured.

Use Axon™ Panel Textured to wrap an entire house for a clean panelised design or mix it up with other wall materials and colours to get a distinctive, modern look. It's made from fibre cement so you can paint it any colour you like, including the modern dark paint colours.

Axon™ Panel can be used in residential or commercial applications wherever a modern design is required, including full cladding for new builds, and cladding for additions and renovations.

Designed to fit common wall frame sizes, Axon™ Panel Textured also makes perfect sense as an aesthetic and water-resistant alternative to plasterboard in semi-wet internal spaces such as laundries, bathrooms and high traffic areas.

NEW Brushed Concrete

The new texture is inspired by the craftsmanship of softly brushed concrete and transforms with light and proximity. The embedded swept texture of these panels give designs a finish that’s visually sophisticated, and dynamic to the touch. It’s perfect for creating modern facades, appearing smooth from a distance, but unexpectedly tactile on closer look, it has the versatility to be used stand alone, or paired with other claddings from the James Hardie range.

Smooth (previously known as EasyLap™ Panel)

We're in the process of re-branding EasyLap™ Panel into Axon™ Panel Smooth. Same great versatile panel just with a new name.

A panel with a shiplap vertical joint and a smooth clean finish. It can be finished with a site applied roll on textured acrylic paint for that rendered look, or you can paint it smooth. It also makes the perfect surface for board and batten applications when used in conjunction with Hardie™ Axent™ Trim.

Features and benefits

• Engineered to stand up to harsh environments, including coastal conditions
• Axon™ Panel has been tested and complies to the new E2/VM2 verification method for building facades up to 25m high, view the CodeMark certification now
• Can be painted a large variety of colours, even the darker shades
• The Hardie™ embedded texture technology of brushed concrete enables consistent textured panels without the need for specialist trades
• Cost effective and long-lasting
• Resistant to fire, rot resistant and resistant to moisture damage
• Up to 60 minute fire resistance rating (FRR) can be achieved when installed as per the Fire and Acoustic Design Manual by James Hardie
• Classified as a lightweight cladding
• Suitable for use where non-combustible materials are required
• Low maintenance
• Easy installation makes Axon™ Panel a fast and effective way to cover your home’s exterior
• GreenTag Certified
• BRANZ Appraised
• CodeMark Certified
• 15 year product warranty

Product profiles

NEW Brushed Concrete

Thickness: 8.5mm
Length: 2440mm, 2750mm, 3000mm or 3600mm
Width: 1200mm

Smooth (previously known as EasyLap™ Panel)

Thickness: 9mm
Length: 2450mm or 3000mm
Width: 1200mm
